What Is Heat Exchanger Plate

Heat exchanger, also known as heat exchanger, is a device that transfers part of the heat of hot fluid to cold fluid.

M15

Small 40kw Plate Heat Exchanger for Refrigeration

Parallel 60 Plate Plate Heat Exchanger for Marine

High Pressure 50 Plate Plate Heat Exchanger

Copper Air To Air 300kw Plate Heat Exchanger for Industrial

Aluminium Small 300kw Plate Heat Exchanger for Industrial

Titanium Steam 80 Plate Plate Heat Exchanger for Industrial

M10

MX25M

What Does A Heat Exchanger Plate Do

Plate heat exchanger is a new type of high-efficiency heat exchanger, which is composed of a series of corrugated plates. Thin rectangular channels are formed between various plates, and heat exchange is carried out through half of the plates. Plate heat exchanger is an ideal equipment for liquid liquid and liquid vapor heat exchange.

Types Of Heat Exchanger Plate

Removable Plate Heat Exchanger

Principle: Heat exchanger, also known as heat exchanger, is a device that transfers part of the heat of hot fluid to cold fluid.

Advantage: High heat exchange efficiency, small heat loss, compact and light structure, small floor area, convenient installation and cleaning, wide application and long service life; Under the same pressure loss, its heat transfer coefficient is 3-5 times higher than that of the tubular heat exchanger, and its floor area is one third of that of the tubular heat exchanger. Its heat exchange efficiency is very high.

Brazed Plate Heat Exchanger

Principle: The brazed plate heat exchanger works by using the second law of thermodynamics and the principle that high-temperature objects spontaneously transmit heat to low-temperature objects. The plates of the brazed plate heat exchanger isolate the cold / hot medium, so that the two media will not be mixed together, and the hot medium transfers heat to the low-temperature medium through the plates of the heat exchanger.

Advantage: Brazed heat exchanger is more resistant to high temperature and high pressure, and can be used in high temperature steam.

Shell And Tube Heat Exchanger

Principle: Shell and tube heat exchanger is the most widely used heat exchanger in chemical industry and alcohol production at present. It is mainly composed of shell, tube sheet, heat exchange tube, head, baffle, etc. The required materials can be made of ordinary carbon steel, red copper, or stainless steel. During heat exchange, a fluid enters from the connecting pipe of the head, flows in the pipe, and flows out from the outlet pipe at the other end of the head, which is called the pipe pass; Another fluid enters from the connecting pipe of the shell and flows out from another connecting pipe on the shell, which is called shell side tubular heat exchanger.

Advantage: It has a long history and the equipment can be used in high-pressure situations.

Advantages Of Our Heat Exchanger Plate

Corrugated plate structure with similar plate heat exchanger, with more advanced all-welding process seal, no gasket design, plus a variety of metal and alloy materials to ensure that MAX full-weld heat exchanger is suitable for temperature -195 ° C to 538 ° C, working pressure from vacuum to 8.2 MPa in almost all heat exchange process applications.

And its compact structure design, efficient heat transfer performance and convenient and flexible use determine the superior performance of completely replacing traditional shell-and-tube heat exchangers.

Cases Of Our Heat Exchanger Plate

Heat exchanger is a device that transfers part of the heat of hot fluid to cold fluid, also known as heat exchanger. Its main function is to ensure the specific temperature required by the process for the medium. It can transfer heat between materials between two or more fluids with different temperatures, so that the heat can be transferred from the fluid with higher temperature to the fluid with lower temperature, so that the fluid temperature can reach the indicators specified in the process to meet the needs of process conditions. At the same time, the heat exchanger is also one of the main equipment to improve energy utilization
